A multifunctional bending machine is a device that can bend thin plates and has the following characteristics:
All steel welded structure: With sufficient strength and rigidity, it can ensure the stability and reliability of the equipment during operation.
Hydraulic transmission: The oil cylinders at both ends of the machine tool are placed on the slider, which can directly drive the slider to work and provide a large bending force.
Sliding block synchronization mechanism: usually adopts torsion axis forced synchronization, with a simple structure, stable and reliable performance, and can ensure high synchronization accuracy of sliding block movement.
Mechanical stopper structure: stable and reliable, can be controlled and adjusted by a CNC system to achieve precise bending size control.
The slider stroke adjustment is convenient: there are both quick and manual adjustments, and it is displayed through a counter, making it easy for operators to grasp the bending process.
Deflection compensation mechanism: For example, a wedge type deflection compensation mechanism helps to achieve high bending accuracy and reduce bending errors of the workpiece.
Multifunctionality: It can meet the bending needs of various shapes and sizes of workpieces by changing different bending molds, and is suitable for various materials, such as metal sheets.
Digital operation: Simple and convenient to operate, with dual functions of manual and automatic states, improving work efficiency and operational flexibility.
Accurate angle, fast speed, and high efficiency: able to quickly and accurately complete bending work, improving production efficiency.
Good processing quality: Ensure that the processed workpiece does not deform, stick to the board, or bubble, and the bending angle range is large, usually reaching 0-179 degrees, meeting different bending angle requirements.
Heating system: Some bending machines are equipped with heating functions, such as infrared heating or stainless steel tube heating, which can achieve heating and softening of the sheet metal, facilitate bending and forming, and the temperature is usually adjustable.
Water circulation cooling system: helps maintain the normal working temperature of the equipment and extends its service life.
Taking a common multifunctional bending machine as an example, its technical parameters may be as follows:
Voltage: 220V;
Heating power: 1200W;
Heating temperature: 650 degrees (temperature adjustable);
Effective bending length: 1200MM;
Bending plate thickness: 0.5MM-10MM;
Bending angle: 0-179 degrees;
Water tank capacity: 30 liters;
Mold pressure bar pressure: 0KG-150KG;
The heating width can be adjusted within a certain range, for example, adjusting the width to 0MM-20mm;
Bending time for each corner: 7-12 seconds;
Whole machine structure: (40402) MM square tube welding or aluminum alloy structure;
Whole machine paint: spray painted and baked.
When using a multifunctional bending machine, operators need to strictly follow safety operating procedures to ensure personal safety and normal operation of the equipment. At the same time, regular maintenance and upkeep of the bending machine can extend its service life and maintain good working performance.
